| Electrical Pediatric Intensive Care Bed | ||
|
||
|
Electrical adjustment of backrest, footrest, height, trendelenburg and reverse trendelenburg
Fowler and vascular positions
Patient hand control and nurse control unit
Auto CPR
Retracting backrest and footrest
Auto contour
Fold down PP siderails
Wire mesh bed platform
Compact laminate bed platform (optional)
Removable head and footboards
Two lockable castors
Central and directional lockable castors (optional)
Electrostatic painted steel frame
Height adjustable stainless steel IV pole
Easy knee break position
Plastic bumpers in the four corners of the bed
Battery backup (optional)
Instant CPR in the Backrest (optional)
Accessories sockets in the four corners of the bed
One button Cardiac chair, shock position, semi- fowler position, bed exit position and examination position adjustments
Hand control unit is lockable to prevent any undesirable position
X-Ray translucent backrest and Cassette holder (optional)
IPX4 standard electronic system
Overall Length: 195 cm
Overall Width: 95 cm
Height Range: 40-76 cm
Trendelenburg: 0°-16°
Reverse Trendelenburg: 0°-16°
Backrest Angle (Max.): 70°
Legrest Angle (Max.): 40°
Castor Diameter: 12,5 cm
Under Bed Clearance: 15 cm
Safe Working Load: 180 kg
Electrical Shock Protection : Class I, Type B
Liquid Ingress Protection : IPX4 - IPX6
Batteries : 2x 12V Series, Connected, Sealed, Rechargeable, Lead / Acid gel, 12 amp hrs.
